SLIMCLIPS

$1.55

Clear
Discount for bulk purchase:
1-24 – $1.55 ea
25-99 – $1.35 ea
100-499 – $1.30 ea
500-999 – $1.20 ea
1000 +4999 – $1.05 ea
+5000 – $0.95 ea
10,000 +above – (please contact us for pricing)
Description

SlimClips Features

  • All stainless steel construction for strength and anti corrosion
  • Comes with stainless nut and kep nut
  • Easy release of wires
  • Wires will not pull out
  • Fit up to 5 ignites in single clip
  • Durable waterproof
  • Comes in red and black:
  • Easy and inexpensive to replace standard mini clips
  • Rugged design can handle the harsh environment expected at a display
  • Fit and finish high quality design
  • Universal design for PCB mount or hardwired
  • These are the actual discount prices
  • Discount quantity on total order
  • NO additional discount
  • 10,000 +above – (please contact us for pricing)
  • Optional solder lug – .10 EA

specification

  • Overall diameter –.506 in (9.00 mm)
  • Overall length – 1.480 inc  (37.59 mm)
  • Height above mounting surface – .5995 inc  (15.23 mm)
  • Depth below mounting surface –  .866 inc  (22 mm)
  • Mounting hole diameter – .275 inc  (7 mm)
  • Mounting surface thickness –  .0315 in-.1187 inc  (0.8mm-4.75 mm)
  • Material – Stainless steel spring, washer, nut and kep nut W/3 mm thread
  • Plastic – Strength nylon
  • Shipping weight – .215 ounces  (6.1 grams)
  • Available colors – Red and black sold individually
  • Note this item is designed for temporary low voltage (48 volts or less)Center post – Stainless steel
 Remember these are stainless steel (not tin plated brass)

SlimClips 2D Drawing

Additional information

Weight N/A
Dimensions N/A
Colour

Red, Black
